Tower fan as one of the common home fans, it is more energy efficient than air conditioning, and the wind is not as cold as air conditioning. Meanwhile, due to the soft air supply, high wind frequency and no dizziness, the tower fan is very suitable for the elderly, children, hospital wards and other people who need care.

In this article, we will give an introduction to the assembly and cleaning of one of tower fans Aibet produced. Hopefully it is helpful for everyone.

Assemble Instructions

1) Remove all items of packing from the tower fan.
2) Pass the power cord through the middle of the two base pieces
3) Position base piece onto the support posts of the other base piece to create the base assembly.
4) Turn the tower body upside down position the base assembly onto the pedestal tube. Ensure that the pedestal tube is sitting flush in the base assembly.
5) Screw the base assembly onto the pedestal tube with the supplied screws.
6) Position the power cord into the provided cord track in the rear base.
7) Turn the tower fan back to upright position.

Please see Exploded Assembly Diagam of tower fan

Cleaning instructions

a) Always disconnect the cord from the electrical outlet before cleaning your fan.
b) Dust may be removed by using a vacuum cleaner along the back of the fan where the plastic grille covers the air intake.
c) Wipe the exterior surfaces of the fan occasionally with a damp cloth (not dripping wet) and dry thoroughly with a soft dry cloth before operating the fan.
d) Do not use harsh cleaners or materials to clean this unit, doing so will cause damage.
e) Unscrew the screw in front of fan grille, open the grille to clean the fan wheel softly.

Please see part list of tower fan we produced so that it is easy to assembly after clearing.

CAUTION: DO NOT ALLOW WATER TO RUN INTO THE INTERIOR OF THE FAN AS THIS COULD CREATE A FIRE OR ELECTRIC SHOCK HAZARD.
